 Specifications:
Description:
Plain annealed flexible copper conductor, flexible PVC bedded, with a Nitrite
PVC sheath.
Application:
For the wiring of:
Control panels and power installations where a flexible conductor is required.
Specification: SANS 1507/2002
Voltage Rating: 600/1000 V
Temperature Range: -10°C to 70°C
Sheath colours Black, red, green/yellow, blue
other colours available on request
Packaging:
Packaging 100 meter
Shrink-wrapped coils
Also available on 500 meter Wooden drums
Technical Information
|
CABLE SIZE |
NOMINAL
STRANDING
No.x DIAMETER |
APPROX.
OVERALL
DIAMETER |
CURRENT
RATING
Note 1 |
VOLT DROP |
APPROX. CABLE
WEIGHT
MASS PER
100M COIL |
|
(mm2) |
|
(mm) |
(A) |
(MV/A/M) |
(kg) |
|
|
|
|
|
(note 1) |
(note 1) |
|
25.0 |
329w x 0.3 |
11.1 |
114 |
0.78 |
29.4 |
|
35.0 |
455w x 0.3 |
12.4 |
141 |
0.554 |
38.7 |
|
50.0 |
670w x 0.3 |
14.8 |
182 |
0.386 |
55.7 |
|
70.0 |
904w x 0.3 |
16.6 |
234 |
0.272 |
73.6 |
|
95.0 |
1190w x 0.3 |
19.1 |
284 |
0.206 |
95.3 |
|
120.0 |
550w x 0.5 |
21.4 |
330 |
0.161 |
131.0 |
Note 1: Based on a max ambient
temperature of 30°C and a max conductor temperature of 70°C
|
